CNC Part 1 (NCK, PLC, drive)
Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
93
Commissioning communication NCK<->Drive
9
Introduction
The first commissioning of the PLC and SINAMICS drives is completed.
What will be configured next?
You will configure the NCK machine data, which communicates with the drive. These are:
• General machine data
General machine data required for communication with the drive, which have been preset
with default values. These values may be taken over during first commissioning. These
are:
– The telegram type for transfer
– The logical addresses for the PLC
Note
The NX is an exception here. For this module the logical address of the PLC must be
entered in the general machine data MD13120[1]
CONTROL_UNIT_LOGIC_ADDRESS.
See also:
Special features when commissioning NX <-> Drive (Page 208)
• Axis-specific machine data
The axis component for transfer of the setpoints and actual values for the relevant axis, is
set in the axis machine data.
