Requirements for commissioning
3.4 Commissioning tool on PG/PC
CNC Part 1 (NCK, PLC, drive)
Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
29
Table 3-1 Network configuration
Component socket Which network? IP address Subnet ID
TCU/PCU 50.3 and
currently PC/PG for
commissioning of
internal HMI
X120 Ethernet 192.168.214.1 255.255.255.0
Factory network X130 Ethernet Assigned by DHCP
server, for example
10.10.255.200
PG/PC for
commissioning of PLC
external HMI
X127 Ethernet 192.168.215.1
or DHCP Server
255.255.255.248
3.4 Commissioning tool on PG/PC
Precondition
If a SINUMERIK 840D sl (internal HMI), consisting of a TCU, NCU 7x0 and SINAMICS S120
drive components is commissioned, the commissioning tool on the PG/PC is required.
To carry out a commissioning with PG/PC with the commissioning tool, the following points
are required:
• Commissioning tool is installed and started on the PG/PC.
• There is an Ethernet connection to NCU (currently X120).
• Since the standard Ethernet IP address is pre-assigned in the commissioning tool for
X120 (192.168.214.1), there are no additional requirements.
• If another Ethernet interface is used, e.g. connected to socket X127, then this must be
adapted accordingly in the commissioning tool by selecting HMI > Change standard
address (for example, 192.168.215.1 for socket X127).
