Commissioning SINAMICS drives
8.7 Checking /setting power supply data settings
CNC Part 1 (NCK, PLC, drive)
90 Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
8.7 Checking/setting power supply data settings
Introduction
The power supply data settings must be checked/set in the SINAMICS during
commissioning.
Procedure for checking/setting power supply data.
Proceed as follows to check/set power supply data in the SINAMICS:
1. Select the machine data for infeed (ALM) in the operating area "Commissioning >
Machine data > Infeed MD".
2. ALM: Set p10=1
3. ALM: Enter p210=current power supply frequency at the site
4. ALM: Enter p211=current power supply voltage at the site
5. ALM: Set p3900=3 (implicit version p340=1)
6. ALM: Set p3410=5 perform power supply identification (see Chapter (Identification ALM >
Infeed/Configuration" Section "Manual power supply identification of ALM")
Saving of changed parameters p210/p211 will be done within the framework of power supply
identification and need not be initiated manually.
See also
ALM identification (Page 91)
