CNC Part 1 (NCK, PLC, drive)
Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
39
Connect PG/PC with the PLC
6
6.1 Start SIMATIC Manager
Introduction
SIMATIC Manager is a GUI for online/offline editing of S7 objects (projects, user programs,
blocks, hardware stations and tools).
The SIMATIC Manager lets you
• manage projects and libraries,
• call STEP 7 tools,
• access the PLC online.
Start SIMATIC Manager
After installation, the SIMATIC Manager icon appears on the Windows desktop, and in the
Start menu a "SIMATIC Manager" program item appears under "SIMATIC".
1. Run SIMATIC Manager by double-clicking the icon, or from the Start menu (same as with
all other Windows applications).
User interface
A corresponding editing tool is started up when you open the relevant objects. Start the
program editor by double-clicking the program block you want to edit.
Online help
The online help for the active window is always called by pressing F1.
