13.4 Integrating PG/PC into the network (NetPro)
CNC Part 1 (NCK, PLC, drive)
192 Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
13.4 Integrating PG/PC into the network (NetPro)
Introduction
To carry out routing functions, it is necessary to integrate a PG/PC in the SIMATIC Manager
under NetPro and to configure the interfaces.
Requirements
You have to have carried out the following as laid out in the previous chapters:
• inserted NCU 720.1 into the HW config,
• configured the properties of the network interfaces,
• configured the PLC to drive communication,
• inserted the machine control panel (MCP),
• saved and compiled the configuration,
• created a PLC program.
See also
Insert NCU 7x0 in HW config (Page 44)
Configuring the properties of the network interfaces (Page 45)
Adding a machine control panel and handwheel in HW Config (Page 223)
End hardware configuration and load to the PLC (Page 53)
Overview Creating a PLC program (Page 54)
