NCK start-up
10.5 Parameterize axis data
CNC Part 1 (NCK, PLC, drive)
Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
131
assigns the machine axis the relevant table of indexing positions and also defines the
machine axis as an indexing axis.
Indexing position tables
The indexing positions are stored in one of two possible tables.
• MD10900 INDEX_AX_LENGTH_POS_TAB_1 (number of positions of indexing table 1)
• MD10910 INDEX_AX_POS_TAB_1[n] (indexing position table 1)
• MD10920 INDEX_AX_LENGTH_POS_TAB_2 (number of positions of indexing table 2)
• MD10930 INDEX_AX_POS_TAB_2[n] (indexing position table 2)
Machine data
Table 10-18 Indexing axes: Machine data
Number Identifier Name Reference
general ($MN_ ... )
10260 CONVERT_SCALING_SYSTEM Basic system switch-over active G2
10270 POS_TAB_SCALING_SYSTEM Measuring system of position tables
10900 INDEX_AX_LENGTH_POS_TAB_1 Number of indexing positions used in Table 1
10910 INDEX_AX_POS_TAB_1[n] Indexing position table 1
10920 INDEX_AX_LENGTH_POS_TAB_2 Number of indexing positions used in Table 2
10930 INDEX_AX_POS_TAB_2[n] Indexing position table 2
Axis/spindlespecific ($MA_ ... )
30300 IS_ROT_AX Rotary axis R2
30310 ROT_IS_MODULO Modulo conversion for rotary axis R2
30320 DISPLAY_IS_MODULO Position display is modulo 360 degrees R2
30500 INDEX_AX_ASSIGN_POS_TAB Axis is indexing axis
30501 INDEX_AX_NUMERATOR Numerator for indexing axes with equidistant positions
30505 HIRTH_IS_ACTIVE Axis is an indexing axis with Hirth toothing
Interface signals
Table 10-19 Indexing axes: Interface signals
DB number Bit, byte Name Reference
Axis/spindle-specific Signals from axis/spindle to PLC
31,... 60.4, 60.5 Referenced/synchronized 1, referenced/synchronized 2 R1
31,... 76.6 Indexing axis in position
Literature
Function Manual Expanded Functions; Indexing axes
