Licensing
14.3 Web License Manager
CNC Part 1 (NCK, PLC, drive)
230 Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
14.3 Web License Manager
By using the Web License Manager, you can assign licenses to hardware in a standard Web
browser. To conclude the assignment, the License Key must be entered manually at the
control system via the HMI user interface.
Internet address
The Internet address of the Web License Managers is:
http://www.siemens.com/automation/license
14.4 Automation License Manager
The Automation License Manager can be used to assign all the licenses required for a piece
of hardware (license-requirement comparison). The license information, including the
License Key, is transferred electronically via an Ethernet link (TCP/IP).
Preconditions:
• The Automation License Manager must be installed on the computer (PC/PG) that is
used to assign the licenses to the hardware.
• The computer (PC/PG) must be able to connect to the license database and the
SINUMERIK control system via Ethernet link (TCP/IP):
– License database: Internet connection
– SINUMERIK control system: Intranet or PTP connection (Ethernet, Peer-To-Peer)
The individual steps for assigning licenses to hardware (license database) and the
transfer of license information from/to the SINUMERIK control system can be performed
such that only one connection must be available at any one time.
14.5 License database
The license database contains all the customer-specific license information relevant to the
license management of SINUMERIK software products. The central management of the
license information in the license database ensures that the existing license information
regarding a piece of hardware is always up to date.
License database access
License database access occurs via:
• Direct access
The direct access occurs with:
– Delivery note number
– License number
The direct access enables the direct assignment of licenses for which the license
numbers are available, e.g., in the form of a CoL.
