Requirements for commissioning
3.2 Software and hardware requirements
CNC Part 1 (NCK, PLC, drive)
26 Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
• You can find all the instructions on how to connect the Ethernet interface here:
Equipment Manual NCU
• To initialize an Ethernet, see also:
HMI commissioning; TCU commissioning
3.2 Software and hardware requirements
Requirements
For the commissioning of SINUMERIK 840D sl, the following points are required:
• Connection to NCU
– Network switch or hub to socket X120
– Ethernet connection of PG/PC to socket X120 or socket X127 when commissioning
the HMI PLC external
– Ethernet machine control panel to socket X120
– Ethernet connection from TCU for internal HMI internal to Ethernet machine control
panel or
– Ethernet connection from PCU 50.3 for HMI external to Ethernet machine control
panel
• Software prerequisites
– SIMATIC STEP 7 as of Version 5.3 Service Pack 3 on PC/PG (SIMATIC Manager)
– STEP7 package for NCU7x0 on PC/PG (Toolbox)
– GSD file (Toolbox)
– CompactFlash Card with software for internal HMI, NCK, PLC and drive
– External HMI on PCU 50.3 or IBN tool on PC/PG for the commissioning of internal
HMI
Note
The order numbers of the SINAMICS drives, motors and encoders should be at hand.
These are used for parameterization.
