Requirements for commissioning
3.2 Software and hardware requirements
CNC Part 1 (NCK, PLC, drive)
Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
27
• Hardware prerequisites
– CompactFlash Card with software for internal HMI, NCK, PLC and drive attached in
NCU
– Dual ventilator fan/battery module (MLFB 6FC5348-0AA02-0AA0) to NCU (see
following figure)
'XDOIDQPRGXOH
3ODVWLFJXLGH
)DQV
%DWWHU\
Figure 3-1 Dual fan/battery module
