Fundamentals
15.6 Machine and setting data
CNC Part 1 (NCK, PLC, drive)
278 Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
15.6 Machine and setting data
Introduction
Adaption of the control at the machine is carried out using the machine and setting data.
Parameter assignment
• Machine data
The machine data (MD) are divided into the following areas:
– General machine data
– Channel-specific machine data
– Axis-specific machine data
– Machine data for control unit
– Machine data for infeed
– Machine data for drives
• Setting data
The setting data (SD) are divided into the following areas:
– General setting data
– Channel-specific setting data
– Axis-specific setting data
• Option data
For enabling options. The option data are included in the scope of delivery.
Overview of machine and setting data
The table below lists the areas for machine and setting data. The List Manual contains a
detailed description.
Table 15-5 Overview of machine and setting data
Range Name
from 2 to 9977 Machine data for drives
from 9000 to 9999 Operator panel machine data
from 10000 to 18999 General machine data
from 19000 to 19999 Reserved
from 20000 to 28999 Channelspecific machine data
from 29000 to 29999 Reserved
from 30000 to 38999 Axisspecific machine data
from 39000 to 39999 Reserved
from 41000 to 41999 General setting data
from 42000 to 42999 Channelspecific setting data
