15.4 Macros for commissioning
CNC Part 1 (NCK, PLC, drive)
Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
267
15.4.2 Procedure for calling ACX macros
Introduction
Warning
Prior to starting the macro for the drive configuration, all drive releases (ON/OFF1, OFF2,
OFF3, etc.) must be switched off.
Process when calling a macro
The principle processes for calling an individual macro are laid out below.
These steps include:
• Process for update macro call 150399 (left in the picture)
• Process for configuration macro call (on the right in the picture)
Note
For an initial commissioning or component replacement, an update of the drive
components to the current software version can be required. The 150399 macro can be
used to update all components.
