CNC Part 1 (NCK, PLC, drive)
Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
179
Managing user data
12
Introduction
Once commissioning of the NCK, PLC and drive has been completed, you can manage the
modified data using the functions below:
• Save/Archive user data
• Series commissioning
• Upgrading, as series commissioning
User data
The following user data can be managed:
Table 12-1 User data
NCK/HMI PLC
Machine data OB (organization blocks)
Setting data FB (function blocks)
Option data SFB (system function blocks)
Global (GUD) and local (LUD) user data FC (functions)
Tool and magazine data SFC (system functions)
Protection zone data DB (data blocks)
R parameters SDB (system data blocks).
Work offsets
Compensation data
Display machine data
Workpieces, global part programs and
subroutines
Standard and user cycles
Definitions and macros
