NCK start-up
10.5 Parameterize axis data
CNC Part 1 (NCK, PLC, drive)
130 Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
Number Identifier Name Reference
axisspecific ($MA_ ... )
30450 IS_CONCURRENT_POS_AX Concurrent positioning axis
32060 POS_AX_VELO Feedrate for positioning axis
Interface signals
Table 10-17 Positioning axes: Interface signals
DB number Bit, byte Name Reference
Axis/spindle-specific Signals from PLC to axis/spindle
31,... 0 Feedrate override, axis-specific
31,... 2.2 Delete distance-to-go, axis-specific
Signals from axis/spindle to PLC
31,... 74.5 Positioning axis
31,... 78-81 F function (feedrate) for positioning axis
Literature
Function Manual Expanded Functions; Positioning axes
10.5.6 Indexed axes/"Hirth" axes
Indexed axes are rotary or linear axes, which can be traversed to indexed positions by index
program instructions.
These indexed positions are approached in JOG mode.
In "normal" positioning, every position can be approached.
Note
Traversing to indexing positions using the parts program or manually is only effective if the
corresponding machine axis has been successfully referenced.
Hirth axes are indexing axes with Hirth tooth system. These axes are rotary or linear axes,
which may only be traversed to defined positions, the indexing positions, within the
traversing range (MD30505 HIRTH_IS_ACTIVE).
The indexing positions are stored in tables.
Indexing axis
Machine data
• MD30500 INDEX_AX_ASSIGN_POS_TAB[n] (axis is indexing axis)
