13.6 Overview - Assignment of SINAMICS and NCK machine data for communication via PROFIBUS
CNC Part 1 (NCK, PLC, drive)
206 Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
13.6 Overview - Assignment of SINAMICS and NCK machine data for
communication via PROFIBUS
Assignment of SINAMICS and NCK machine data for communication
The table below uses a sample to SINAMICS S120 component configuration to illustrate the
assignment of the communication parameters. The SINAMICS S120 drive group comprises
the following:
• an NCU (CU),
• an ALM,
• Three Motor Modules (MM)
Note
In the Control Unit Parameter 978, deactivate the process data exchange with the value
"0". Cyclic and acyclic data are separated. Components that do not communicate on
PROFIBUS are to be preassigned "255".
