Fundamentals
15.6 Machine and setting data
CNC Part 1 (NCK, PLC, drive)
Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
279
Range Name
from 43000 to 43999 Axisspecific setting data
from 51000 to 61999 General machine data for compile cycles
from 62000 to 62999 Channel-specific machine data for compile cycles
from 63000 to 63999 Axis-specific machine data for compile cycles
See also
Overview Commissioning NCK (Page 97)
15.6.1 Machine data fundamentals
Introduction
Machine and setting data are parameterized via:
• Number and identifier
• Activation
• Protection levels
• Unit
• Default value
• Value range (minimum and maximum)
Number and identifier
Machine data and setting data are identified using the number or the name (identifier). The
number and name are displayed at the HMI.
The identifier of a machine data is subject to the scheme:
• $ M k _IdentifierString
where the following applies:
– $System variable
– MMachine data
– kComponent
k identifies the components of the NC parameterizing the appropriate machine data:
– NNC
– CChannel
– AAxis
The identifier of a setting data is subject to the scheme:
• $ S k _IdentifierString
