NCK start-up
10.5 Parameterize axis data
CNC Part 1 (NCK, PLC, drive)
140 Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
Notice
Depending on MD30300 IS_ROT_AX[n], the velocities have to be entered in mm/min,
inch/min, or rpm.
If the velocities are changed, MD36200 AX_VELO_LIMIT[n] (threshold value for velocity
monitoring) must be adapted accordingly.
Machine data
Table 10-23 Velocities: Machine data
Number Identifier Name / remarks Reference
axis-spec. ($MA_ ... )
30300 IS_ROT_AX[n] Rotary axis
32000 MAX_AX_VELO[n] Maximum axis velocity G2
32010 JOG_VELO_RAPID[n] Rapid traverse in JOG mode
32020 JOG_VELO[n] JOG axis velocity
32040 JOG_REV_VELO_RAPID[n] Revolutions feedrate in JOG mode with rapid
traverse override
32050 JOG_REV_VELO[n] Revolutional feedrate in JOG mode
32060 POS_AX_VELO[n] Initial setting for positioning axis velocity P2
32250 RATED_OUTVAL Rated output voltage
32260 RATED_VELO[n] Rated motor speed
Setting data
Table 10-24 Velocities: Setting data
Number Identifier Name / remarks Reference
General ($SN_ ...)
41100 JOG_REV_IS_ACTIVE Revolutional feedrate in JOG mode active
41110 JOG_SET_VELO JOG velocity for linear axes (for G94)
41120 JOG_REV_SET_VELO JOG velocity (for G95)
41130 JOG_ROT_AX_SET_VELO JOG speed for rotary axes
41200 JOG_SPIND_SET_VELO JOG velocity for the spindle
Literature
Function Manual Basic Functions;
Speeds, setpoint/actual value systems, control, Chapter "Speeds, traversing ranges,
accuracy"
Function Manual, Expanded Functions; Manual and Hand Wheel Travel
