NCK start-up
10.6 Parameterization of spindle data
CNC Part 1 (NCK, PLC, drive)
Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
163
• Pulse multiplication = 128
• Internal precision = 1000 [increment/degree]
• Sensor ratio = 1:1
• Load ratio = 1:1
The machine data are set acc. to the values above:
• MD10210 INT_INC_PER_DEG (computational resolution) = 1,000 [incr./degree]
• MD31020 ENC_RESOL (encoder resolution) = 500 [pulses/revolution]
• MD31050 DRIVE_AX_RATION_DENOM (load rev. denominator) = 1
• MD31060 DRIVE_AX_RATION_NUMERA (load rev. numerator) = 1
• MD31070 DRIVE_ENC_RATION_DENOM (sensor speed denominator) = 1
• MD31080 DRIVE_ENC_RATION_NUMERA (sensor speed numerator) = 1
,QWHUQDO
5HVROXWLRQ
GHJUHH
0'SXOVHUHY
0'
0'
0'
0'
0'
HQFRGHUSXOVH
LQWLQFUHPHQWV
,QWHUQDO
5HVROXWLRQ
One encoder increment corresponds to 5.625 internal increments.
One encoder increment corresponds to 0.005625 degrees (highest possible positioning
resolution).
Example B: encoder at motor
Suppose the following conditions are provided:
• The incremental encoder is mounted on the motor.
• Encoder pulses = 2048 [pulses/rev.]
• Pulse multiplication = 128
• Internal precision = 1000 [increment/degree]
• Sensor ratio = 1:1
• Load ratio 1= 2.5:1 [motor speed/spindle speed]
• Load ratio 2= 1:1 [motor speed/spindle speed]
Gear stage 1
0'
0'
0'
0'
0'
,QWHUQDO
5HVROXWLRQ
GHJUHH
0'SXOVHUHY
