Managing user data
12.4 Series commissioning
CNC Part 1 (NCK, PLC, drive)
Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
183
Operating sequences
1. Open the menu to create a series-commissioning file:
Operating range "Services > ETC key ">" > "Series IBN".
2. Create an archive for the series-commissioning file: You can select which data you wish
to save as the archive contents:
– HMI
– NC with compensation data
– PLC
– Profibus drives
3. Archive name: The suggested archive name depends on the selected area and can be
changed if necessary.
4. Create the series-commissioning file by selecting the component to which you wish the
file to be output:
– NC-Card
– Archive
