Tips
13.1 Configuration of the properties of the network interface for PROFIBUS
CNC Part 1 (NCK, PLC, drive)
Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
187
8. Module NCU 720.1 with SINAMICS S120 is inserted into the HW config (see figure
below).
Note
With the <F4> key and confirmation of the question regarding "Reorganize", you can
reorganize the display in the station window.
Figure 13-4 HW config with NCU 7x0
As the next step configure a machine control panel with hand wheel.
