PLC commissioning
7.1 Creating a SIMATIC S7 project
CNC Part 1 (NCK, PLC, drive)
Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
49
The interface of socket X120 is used for the current commissioning of the internal HMI. The
IP address must be changed.
1. For socket X120, enter the IP address "192.168.214.1" and the Subnet screen form
"255.255.255.0".
2. Create the Ethernet interface using "New" and then "OK".
3. Click on "OK" twice.
Next, specify the properties for the integrated PROFIBUS.
