4
Machine operating area 01/2008
4.5 MDA mode
4
© Siemens AG 2008 All rights reserved.
4-130 SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition
4.5.3 Teach in
Function
With the "Teach-in" function, part programs (main programs and
subprograms) for motion sequences or simple workpieces can be
created, edited and executed by approaching and then storing
positions in combination with the "MDA" function.
There are two possible methods of writing programs with
"Teach-in" and "MDA":
1. Manual positioning
2. Manual input of coordinates and additional information
Both entry of blocks (input, delete, insert) and automatic insertion by
manual approach of positions are possible only at points that have not
yet been executed.
1. Manual positioning
Sequence of operations
"MDA" mode is selected in the "Machine" operating area.
Teach In
Submode "Teach-in" is selected.
After selection of the function, the cursor is located in the first blank
line of the "Teach-in program" window.
+X
...
X
Turning machine:
Press the "Axis" keys.
X
...
9th Axis
Milling machine:
Select the axis to be traversed.
9th Axis
...
+
then press the "-" or "+" key.
The axis name and the path being traversed are displayed
continuously on the screen in the "Teach-in program" window.
The axis identifier and axis positions are transferred to the MDA
program as values referred to the workpiece coordinate system.
