SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition 4-95
X
...
9th Axis
Milling machine:
Select the axis to be traversed and
...
+
then press the "-" or "+" key.
Traverse the axes to the point of interruption.
4.2.2 Displaying the program level
Function
If subprograms are called while a part program is running, the block
numbers for the main program and subprograms together with their
pass number (P) can be displayed.
Sequence of operations
"AUTO" mode is selected in the "Machine" operating area.
When you press the "Program level" softkey, the window headed
"Program level" appears instead of the "Current block" window. The
softkey labeling changes to "Current block".
During execution of a part program, the block numbers for the main
program and subprograms, together with their pass number (P), are
displayed in the "Program level" window. The main level is always
visible, a nesting depth of up to 12 can be displayed.
Current
block
When you press the "Current block" softkey, the "Current block"
window containing the program blocks of the current part program is
displayed again.
