2
01/2008 Operator Components/Operating Sequences
2.7 Job list
2
©Siemens AG 2008 All rights reserved.
SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition 2-77
2.7.4 “Execute job list” operating sequence
Manage
data
e.g., press the "Manage data" softkey under "Services".
The horizontal and vertical softkey bars change.
Position the cursor on the correct workpiece directory.
Load
Selection
Unload
Then execute functions
"Load"
"Select"
"Unload"
If a job list named Workpiece.JOB is stored in a workpiece directory,
then the functions are executed for that job list.
However, the functions can be executed directly on the job list, e.g., if
the directory contains job lists that are named differently from the
workpiece.
Additional information
Load
"Load" job list
"Load" means that all the prepared job list instructions are executed.
The data is distributed from [Source] to [Destination], to the
destination NCs with the instruction LOAD or COPY. The workpiece is
then marked as "loaded".
SELECT instructions are ignored.
If the workpiece/job list is loaded, then the log window displays a list of
the files to be distributed.
The log window can be displayed in the event of an error. Loading of
the job list can then be aborted if necessary.
Marking of files on user interface
If the file is stored only on the hard disk of the HMI, then it is marked
as "not loaded".
If the file is only located in the working memory of the NC, it is marked
as loaded with an "X".
If the file is located both on the HMI and the NC, the identifier "X" is
only removed when the files are no longer identical.
If the files have different time stamps or are of different lengths, the
identifier is "!X!".
