01/2008 Parameters operating area
5.8 Display system variables
5
© Siemens AG 2008 All rights reserved.
SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition 5-247
5.8.2 Managing variable views
Function
The views you create are stored and managed in file form.
Sequence of operations
Edit
view
Manage
views
New
file
File
contents
Delete
file
With the "Edit view" and "Manage views" softkeys you can open a
window in which files and views can be
• created
• displayed and
• deleted.
File
contents
Display
view
The "File contents" softkey takes you to another window in
which the views of the previously selected file are
displayed. With the "Display view" softkey you exit the
dialog box and the previously selected view is displayed on
the "System variable views" screen.
New
view
Delete
view
Save
view
These softkeys also enable you to create views,
delete views and
save the currently displayed view under a selected name.
