Page #145 background image
4
01/2008 Machine operating area
4.6 Automatic mode
4
© Siemens AG 2008 All rights reserved.
SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition 4-145
The following search types can be entered:
Search type (= jump to ...)
Value in search type field
End of program 0
Block number 1
Jump label 2
Any character string 3
Program name 4
Line number 5
Different search types can be specified for different program levels.
A
...
Z
You can enter your chosen search target (according to search type) in
the "Search target" field.
0
...
9
You can enter the corresponding number of program passes in the "P"
field (pass counter).
Preassign search target as last program interruption point:
Interruption
point
The search pointer is assigned the data of the last program
interruption point.
4.6.9 Accelerated external block search
Function
The block search function allows you to run the part program forward
until you reach the block you require.
You can use the "External without calc." softkey in the "Search
position" and "Search pointer" menus to start an accelerated block
search in programs that are executed from an external device (local
hard disk or network drive).
The search target can be determined:
By directly positioning the cursor on the target block, or
Specifying a block or line number
Block search sequence:
Only those programs and program parts which are needed in order to
reach the specified search target and to continue program execution
are transferred to the NC.
This applies to the following:
“Execution from external source”
Execution of EXTCALL instructions
