8
01/2008 Diagnostics operating area
8.4 Service displays
8
© Siemens AG 2008 All rights reserved.
SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition 8-413
8.4.5 Configuration data output
Function
The configuration data of a machine (HMI version, NCU version, axis
configuration, drive configuration, bus parameters, active bus nodes)
can be written into a file and subsequently read out or printed.
Configuration data is output in 2 stages:
1. Creation of the configuration data file CONFIGURATION_DATA in
the "Diagnostics" operating area by pressing the "Config. data"
softkey.
2. Read-out of the CONFIGURATION_DATA file in the “Services”
operating area. The configuration file CONFIGURATION_DATA is
created in the "Services" operating area for this purpose.
Sequence of operations
Service
displays
Select the menu "Service displays".
The horizontal softkey bar changes.
Config.
data
Press the "Config. data" softkey.
The system gathers the configuration data, writes it into the file
CFGDAT.TXT and displays it.
The path and name of the file are output in the info line.
Additional information
The configuration data can be read out in the “Services operating
area.
8.4.6 Communication error log
Communic.
log
Function
Errors that occur during communication between the HMI and
NCK/PLC are registered in a communication error log.
You can display the errors by pressing this softkey.
The error log file is principally used by the control manufacturer
(Siemens) as a diagnostic tool for communication errors.
