Page #103 background image
4
01/2008 Machine operating area
4.2 General functions and displays
4
© Siemens AG 2008 All rights reserved.
SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition 4-103
4.2.9 Displaying spindles
Function
The current spindle values (actual speed, setpoint speed, position on
oriented spindle stop and spindle override) can be displayed.
Sequence of operations
"AUTO"/"MDA"/"JOG" mode is selected in the "Machine" operating
area.
The "Spindle" window appears on the screen.
The window contains the spindle setpoint and actual value, position,
setting of spindle override switch and spindle output.
or
Using the "Page" keys you can scroll up or down to display other
spindles - if any are configured.
Additional information
The "Spindle" window is only displayed if at least one spindle is
configured.
If a master spindle is configured, this is automatically displayed in
the spindle window, even if it is not the first spindle.
The following spindle states are output as symbols for the spindles
displayed in the spindle window:
"Spindle STOP"
“Spindle is not enabled”
"Spindle direction of rotation counter-clockwise" or "... clockwise"
(=spindle running)
