Function
Files/directories can be created, loaded, saved, deleted or copied and
their attributes can be displayed/changed in the “Manage data” dialog.
Workpieces, part programs, subprograms, standard cycles, user
cycles and manufacturer cycles can also be managed as in the
program main screen.
This ensures standardized data management.
This affects the following applications:
• Creating new directories and programs
• Loading programs and files to the program memory
• Loading programs and files from the program memory to the hard
disk (unloading the program memory)
• Creating new files
• Copying and pasting files
• Deletion operations
Comparison Vertical softkeys
Main screen in operating area Main screen in operating area
Programs Services
Directories/workpieces/ Data/files/comments
Programs/files Definitions/part programs
Main menu: Manage programs: Manage data:
New... New... New...
Load
HD->NC
Copy
Load
HD->NC
Unload
NC->HD
Paste
Unload
NC->HD
Simulation Delete Delete
Manage
programs...
Rename
Properties
Selection
Change
enable
Copy
Save setup
data
<<
Paste
