5
Parameters operating area 01/2008
5.7 Define user data
5
© Siemens AG 2008 All rights reserved.
5-242 SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition
5.7.3 Activate user data (GUD)
Function
Create a definition file for user data:
• In the "Services" operating area using the "Manage data" softkey
• in the "Definitions" directory
Response
If a definition file is edited in the NC, when exiting the Editor you are
prompted whether the definitions are to be activated.
OK
Abort
Example:
"Do you want to activate the definitions from file GUD7.DEF?"
"OK" Æ A query is displayed asking if the currently active
data should be saved. “Should the previous definition data
be retained?”
"OK" Æ The GUD blocks of the definition file to be
edited are saved, the new definitions are
activated and the saved data
are imported again.
"Abort" ÆThe new definitions are activated, the old data
are lost.
"Abort" ÆThe changes in the definition file are
discarded, the associated data block is not
changed.
Unload
If a definition file is unloaded, the associated data block is deleted
after a query is displayed.
Activate
If a definition file is loaded, a prompt is displayed asking whether to
activate the file or retain the data. If you do not activate, the file is not
loaded.
If the cursor is positioned on a loaded definition file, the softkey
labeling changes from "Load" to "Activate" to activate the definitions. If
you select "Activate", another prompt is displayed asking whether you
want to retain the data.
