6
01/2008 "Program" operating area
6.9 Managing programs
6
© Siemens AG 2008 All rights reserved.
SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition 6-343
E.g., you can select the following data types:
• R parameters (RPA)
• Work offset (UFR)
• Setting data (SEA)
• ...
If a job list exists, it is used as the basis for the save procedure.
Save
With the "Save" softkey, you store the workpiece data of the selected
data types in the relevant workpiece directory.
If a job list exists in this workpiece directory, the data for all the
channels involved in the workpiece are automatically backed up. For
this, the main program selected at the beginning is searched for each
channel in the job list. The data are then backed up according to the
data types selected under its name.
Load
standard
With the „Load Standard softkey you can load the default settings for
input window "Save workpiece data".
Note:
Default settings are always supplied by SIEMENS.
Set
standard
Press this softkey if you want to define your own defaults in the input
window.
6.9.4 Selecting a program to be executed
Function
Workpieces and part programs must be selected for
machining/execution before you press the NC Start key.
Sequence of operations
Select a program:
Part
programs
Selection
Use the cursor keys to select a program in the
program overview, e.g., part programs, and
then press the "Selection" softkey.
The program name is displayed in the "Program name" window at the
top right.
Cycle Start
You can start the part program by pressing "NC Start".
