2.7.3 Example of a job list with multi-channel m:n links
Example
HMI1 to two NCs
NCU1 with channel1 and channel2
NCU2 with channel3
Part1.JOB:
COPY /MPF.DIR/Gen.MPF NC=NCU1 (or CH=CHANNEL1)
COPY /Work.DIR/Part1.WPD/WpdGen.MPF NC=NCU1
(or CH=CHANNEL1)
COPY /Work.DIR/Part1.WPD/Channel1.MPF NC=NCU1
(or CH=CHANNEL1)
COPY /Work.DIR/Part1.WPD/Channel1.INI NC=NCU1
(or CH=CHANNEL1)
COPY /Work.DIR/Part1.WPD/Ch12.MPF NC=NCU1
(or CH=CHANNEL1)
COPY /Work.DIR/Part1.WPD/Channel2.MPF NC=NCU1
(or CH=CHANNEL2)
COPY /Work.DIR/Part1.WPD/Channel2.INI NC=NCU1
(or CH=CHANNEL2)
COPY /Work.DIR/Part1.WPD/Ch22.MPF NC=NCU1
(or CH=CHANNEL2)
COPY /MPF.DIR/Gen.MPF NC=NCU2 (or CH=CHANNEL3)
COPY /Work.DIR/Part1.WPD/WpdGen.MPF NC=NCU2
(or CH=CHANNEL3)
COPY /Work.DIR/Part1.WPD/Channel3.MPF NC=NCU2
(or CH=CHANNEL3)
COPY /Work.DIR/Part1.WPD/Channel3.INI NC=NCU2
(or CH=CHANNEL3)
COPY /Work.DIR/Part1.WPD/Ch32.MPF NC=NCU2
(or CH=CHANNEL3)
SELECT /Work.DIR/Part1.WPD/Channel1.MPF CH=CHANNEL1
SELECT /Work.DIR/Part1.WPD/Channel2.MPF CH=CHANNEL2
SELECT /Work.DIR/Part1.WPD/Channel3.MPF CH=CHANNEL3
