Siemens SINUMERIK 840Di sl User Manual

5
01/2008 Parameters operating area
5.3 Tool management
5
© Siemens AG 2008 All rights reserved.
SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition 5-191
5.3.2 Displaying/editing tool data
Function
You can view and edit the tool data of the tool selected in the lists.
You can edit the following cutting edge data:
• Corrective values
• Monitoring data
• User data
Sequence of operations
Tool
managem.
Press the "Tool management" softkey.
The list configured by the machine manufacturer appears (e.g., the
magazine list). The horizontal and vertical softkey bars change.
Select the appropriate list via softkey:
Magazine
list
• "Magazine list"
Tool list
• "Tool list"
Working
offset
• "Working offset list"
Position the cursor bar on the appropriate tool. The tool is selected.
Notice:
Please ensure that the channel in which the offsets are to be applied
is displayed.
Tool details
Select the "Tool details" softkey.
The input screen for "Tool details" appears.
The vertical softkey bar changes again.
The following functions are available:
• Create new cutting edges
• Edit cutting edge data
• Edit monitoring data
• Edit local offsets (DL numbers)
• Delete cutting edges
