4
Machine operating area 01/2008
4.6 Automatic mode
4
© Siemens AG 2008 All rights reserved.
4-146 SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition
Example:
The following search targets are entered in the Block search menu:
Search target 1 “Level1”: MAIN1.MPF "Line": 8
Search target 2 “Level2”: SUBPRG2.SPF "Line": 4000
Search target 3 “Level3”: SUBPRG3.SPF "Line": 2300
Programs
MAIN1.MPF
1 G90
2 X100 Y200 F2000
3 EXTCALL "SUBPRG1"
4 X200 Y400
5 EXTCALL "SUBPRG2"
6 EXTCALL "SUBPRG3"
7 X0 Y0
Search target 1 8 EXTCALL "SUBPRG2"
9 X50
10 M30
SUBPRG2.SPF
1 X200 Y300
2 X400 Y500
3 EXTCALL "SUBPRG3"
.
.
Search target 2 4000 EXTCALL "SUBPRG3"
.
.
5000 M17
SUBPRG3.SPF
1 X20 Y50
2 .
.
Search target 3 2300 X100 Y450
.
.
5000 M17
