5
01/2008 Parameters operating area
5.2 Tool offset
5
©Siemens AG 2008 All rights reserved.
SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition 5-175
Tool wear: Fine offset
If you at least have the right entered in MD 9202:
USER_CLASS_TOA_WEAR, you can incrementally change the
values of the tool fine offset. The difference between the old and new
values must not exceed the limit stored in MD 9450:
WRITE_TOA_FINE_LIMIT.
Horizontal softkeys
You can select different data types with the horizontal softkeys:
Tool
offset
Selection of "Tool offset" menu
R-
Parameter
Selection of "R parameters" menu
Setting
data
Selection of "Setting data" menu
Work offset
Selection of "Work offset" menu
User
data
Selection of "User data" menu
Determine
offset
Support in determining tool offsets. This softkey is not required if the
tool management function is available.
Vertical softkeys
The vertical softkeys support data input:
T-No.
+
Selection of the next tool
T-No.
-
Selection of the previous tool
D-No.
+
Selection of next highest offset number (cutting edge)
D-No.
-
Selection of next lowest offset number (cutting edge)
Delete...
Deletion of a tool or cutting edge
Go to...
Find any tool or the active tool
Overview
List of all available tools
New
New cutting edge or a new tool
