5
01/2008 Parameters operating area
5.3 Tool management
5
© Siemens AG 2008 All rights reserved.
SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition 5-199
Angle of the inclined wheel [degrees] $TC_TPG8
Parameter number for radius
calculation/compensation
parameter for GWPS
- $TC_TPG9
Additional information
For information on NC variables, please refer to the Function Manual
/FB/, W4 Grinding-specific tool offset and monitoring.
Bottom section:
Tool OEM data are displayed as on the main screen for tool details.
The tool OEM data can be edited on both the grinding parameters
screen and the main tool details screen. The designation and the unit
in the OEM data can be parameterized in the relevant language. The
bottom section of the display is only available if tool OEM data are
available on the NC.
Scroll bar A scroll bar appears next to the middle and bottom sections if the
bottom section is displayed.
The grinding parameters screen and the softkeys are only displayed if
the tool is a grinding tool (tool type between 400 and 499).
Access rights are checked for grinding parameters.
Default access is "All".
All tool cutting edges are of the same type. The same applies to the
dresser cutting edges of grinding tools.
Tool types The tool types for grinders are 4xy in accordance with /FB/, W4.
They are available in displays/functions for:
• Tool cabinet
• Tool catalog
• Cutting edge parameters in tool details
• Lists (magazine list, tool list, working offset list)
Limitations - The tool-specific grinding parameters cannot be displayed in the
list displays.
- They are not saved in the tool cabinet/tool catalog.
- They are not transferred via code carrier/SINCOM.
- The extension is available in HMI Advanced Version 6.2
or later.
