1
01/2008 Introduction
1.3 Switching on/switching off the control
1
© Siemens AG 2008 All rights reserved.
SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition 1-21
Sequence of operations
When you press the "Area switchover" key, operating areas are
displayed on the horizontal softkey bar and operating modes are
displayed on the vertical softkey bar. You can use this key to go to the
area menu bar from any location in the menu hierarchy if you wish to
select another operating mode or a different operating area.
H0.000000
H0.000000
H0.000000
+ X 900.000 mm
- Y -156.000 mm
+ Z 230.000 mm
Act. 3000.000 0.0 %
Set. 3000.000
G1
Services
By pressing the "Area switchover" key twice, you can toggle between
the operating areas last selected, e.g. between the "Parameters" and
"Machine" areas.

