5
Parameters operating area 01/2008
5.8 Display system variables
5
© Siemens AG 2008 All rights reserved.
5-250 SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition
Variable values marked by the cursor line are displayed on the left of
the display.
You do not need to normalize the display in any way, normalization
values are calculated automatically. The characteristic is automatically
normalized to values between minimum and maximum. Binary signals
are represented in expanded form.
