01/2008 "Program" operating area

6.9 Managing programs

SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition 6-345

3. /CUS.DIR / name.type User cycles

4. /CMA.DIR / name.type Manufacturer cycles

5. /CST.DIR / name.type Standard cycles

Case 2: When a subprogram is called by

name without specification of the data type ("identifier" or

"extension"),

e.g. SHAFT1

the system searches through the directories in the following sequence:

1. Current directory / name Workpiece/standard

directory MPF.DIR

2. Current directory / name.SPF

3. Current directory / name.MPF

4. /SPF.DIR / name.SPF Subprograms

5. /CUS.DIR / name.SPF User cycles

6. /CMA.DIR / name.SPF Manufacturer cycles

7. /CST.DIR / name.SPF Standard cycles

References /PGA/, Programming Guide Advanced

Machine manufacturer

see the machine manufacturer's information.

Preconditions:

- A main program (MPF) in the workpiece directory is

selected

"NC Start" was activated

$MN_WPD_INI_MODE=0:

The INI file with the same name as the selected workpiece is

executed.

For example, if SHAFT1.MPF is selected, SHAFT1.INI is

executed when “NC Start” is pressed.

(Behavior as with previous software versions)

$MN_WPD_INI_MODE=1:

All files of type INI, SEA, GUD, RPA, UFR, PRO, TOA,

TMA and CEC which have the same name as the selected main

program are executed in the specified sequence.

• The main programs stored in a workpiece directory can be

selected and processed by several channels.

References Commissioning Manual HMI-Advanced (IM4)
