Siemens SINUMERIK 840Di sl User Manual

7
01/2008 Services operating area
7.4 Transfer display MD from HMI Embedded
7
© Siemens AG 2008 All rights reserved.
SINUMERIK 840Di sl/840D sl/840D Operating Manual HMI-Advanced (BAD) - 01/2008 Edition 7-381
Target directory
Select the target directory
Diagnostics\MachDat\OperatorPanel
Paste
Activate inserted display machine data via Commissioning:
Commissioning → Machine data →
Display MD → File functions
Set up directory and file BDyy.tea
→Load
Additional information
HMI Embedded manages more display machine data than HMI
Advanced. An entry is made in the error log for each proposed display
machine data that is not defined in HMI Advanced or contains an
error.
Case 2 acc. to diagram
Transfer display MD to floppy disk or network drive:
On the HMI Embedded system:
Program → ETC →
Set up operator data BDx.tea
→Copy
→ ETC
Select destination medium: Network drive or floppy disk
Paste
On the HMI Advanced system:
Services → Manage data
Select transfer medium: Network drive or floppy disk
Select BDxxyy.tea
→Copy
Continue as for the 1st case, destination directory, see above.
