Procedure for models up to and including 15K
1. If you are making the cable yourself, connect the wires as shown in the following diagram:
Solar-Log™ terminal strip connector Inverter COM1 (RS485)
Terminal PIN
► 1 (Data+) A ► 3 RS485 A
► 3 GND ► 2 GND
► 4 (Data-) B ► 4 RS485 B
2. Connect the round plug with the inverter‘s COM1 round socket.
3. Terminate the inverter according to the manufacturer‘s instructions if no additional inverters are to be
connected.
4. Insert the terminal block connector into the Solar-Log™ RS485 socket.
Connect the inverters to each other
•
Wiring using Polycab‘s daisy chain cable.
•
Connect the cables according to the inverter manufacturer‘s instructions.
•
Terminate the last inverter according to the inverter manufacturer‘s instructions.
Assign the communication address
•
Recommendation: Continuous numbering starting with 1.
•
Default settings on the inverter: Communication address 1
•
Setting: Using the inverter operating display
•
Procedure: Start according to the inverter manufacturer‘s instructions.
Procedure for models 20K and larger:
1. If you are making the cable yourself, connect the wires as shown in the following diagram:
Solar-Log™ terminal strip connector Inverter RJ45
Terminal Pin
► 1 (Data+) A ► 1 RS485 A
► 1 (Data+) A ► 4 RS485 A
► 4 (Data-) B ► 2 RS485 B
► 4 (Data-) B ► 5 RS485 B
2. Insert the RJ45 connector into the inverter‘s COM2 socket.
3. Terminate the inverter according to the manufacturer‘s instructions if no additional inverters are to be
connected.
4. Insert the terminal block connector into the Solar-Log™ RS485 socket.
Connect the inverters to each other
•
Wiring using Polycab‘s daisy chain cable.
•
Where to connect: COM round socket on the inverter
