481
Sensor Basic
Terminal block connector Solar-Log™ Sensor Basic Cable
► 1 (Data+) ► Brown Data+
► 2 (+12V) ► Red +12Vdc (Vcc)
► 3 (GND) ► Black 0 V (GND)
► 4 (Data-) ► Orange Data-
Startup
1. When the Solar-Log™ is switched on, the Sensor Basic is also powered up automatically
2. The Sensor Basic must then be configured on the desired RS485 interface:
3. Use the web interface to access the Solar-Log™ configuration menu.
4. Select “M&T Sensor” for the inverter selection in the
Configuration | Devices | Definition | Interfaces menu in
the sector
Device class | Manufacturer.
5. Carry out the inverter detection. The Sensor Basic is integrated with the system in the same way as an inverter.
