© Stäubli 2009 –
D28070504A
CS8C
204 / 248
8.8.2.
ACCESS
•
Remove the
4
screw
s
(1)
and pull the
RSI
(2)
.
Figure
8.43
8.8.3.
T
ROUB
LE SHOOTING
8.8.3.1.
CASE
1
•
Check
ARPS
(see chapter
8.6
, page
176
).
•
Check wiring between
ARPS
J1102
and
RSI
J104
.
Figure
8.44
•
Change the
RSI
.
Problem:
D49
remains off (
24V1
from
ARPS
).
Solution:
1
2
?
RSI
AR
P
S
J1102-4
J1102-12
J104-1
J104-6
24V1
0V1
24V1
0V1
203
205
