© Stäubli 2009 –
D28070504A
CS8C
206 / 248
8.8.3.4.
CASE
4
Figure
8.45
•
Check
F5
and
F6
fu
ses on
RSI
. If fuses are
blown, check that
there is no short circuit in
the wiring from
RSI
to the arm and no
short circuit in the valves.
•
Change the
RSI
.
Problem:
D73
(EV1)
or
D74
(EV2)
remains Off when correspondin
g I/O on front panel is se
t to On.
Solution:
?
-
I/O
-
Controller
-
UserIO
+
Inputs
0 valve = on
D74 =
ON
D73 =
ON
1 valve = on
-
Outputs
205
