Chapter 8 - Maintenance
•
The
ST
ARC
board can be remove
d after taking out the
fastening screw
(3)
.
•
The
PCI
boards are locked on back edge
with an adjustable plate. This plate can be re
-
ajusted if necessary when board
is replaced.
Figure
8.67
DANGER:
The heat-sink of
the
CPU
board may be ho
t, especially
in the event
of a
ventilation failure.
