Operating & Maintaining the Objet1000 Plus 3D Printer
6–48
DOC-06810 Rev. A
10. Pressdownontheupperandlowerlockingscrewstoreleasetheprint
head.
Figure 6-69: Releasing the print head
11. Loosenthescrewsonthedoorofthecompartmentprotectingthe
print‐headdrivercards(A),thenpullandliftupthedoor(B).
Figure 6-70: Opening the print-head compartment
12. Pulltheprint‐headdrivercardoutofitssocketsothattheheadisfree
(A)andremoveitfromthebottomoftheprintblock(B).
Figure 6-71: Releasing the print-head driver card to remove the head
