Stratasys Objet260 Connex - Display Colors

DOC-06810 Rev. A 5–61
Objet1000 Plus User Guide
Display Colors
YoucancustomizesomeofthecolorsusedfordisplayingObjetStudio
screensandfordisplayingobjectsonthebuildtray.
To change the colors used in Objet Studio screens:
1. FromtheToolsmenu,selectOptions.
Figure 5-86: Display settings
2. IntheAppearancetaboftheOptionsdialogbox,youcanconfigurethe
display.
• TheModeselectiondetermineshowmodelsappearonthebuild
tray.Thedefaultmethodfordisplayingmodelsonthebuildtrayis
assolid(“shaded”)objects.Theotheroptionsare
WireFrameand
Points.
• IfShadedisselected,youcandisplaythemodelonthetrayasasee‐
throughobject.
Figure 5-87: Transparent display
• Double‐clickthecolorpatchestocustomizecolors.
• TheWindowsBackgroundColorsettingsenableyoutochangethe
colorbehindthebuildtray—witheitherasolidoratwo‐color
gradient.
• Toreturntothedefaultdisplaysettings,clickDefault.
