Stratasys Objet260 Connex - Objet Studio Software

DOC-06810 Rev. A 3–9
Objet1000 Plus User Guide
Objet Studio Software
ObjetStudiosoftwarefortheObjet3Dprintingsystemconsistsoftwomain
screens:
• TraySettings/ModelSettings
• JobManager
Tray Settings / Model Settings
IntheTraySettingsandModelSettingsscreens,youpreparesourcefilesfor
productioninObjet3Dprinters.ObjetStudiooffersyouawidevarietyof
file‐preparationoptions,butalwaysconsistsofthefollowingbasic
procedure:
1. Insertingoneormoreobjectsonthebuildtray
2. Positioningtheobject(s)onthetray
3. Configuringobjectandtrayparameters
4. Savingthetrayconfigurationasanobjtf(ObjetTrayFormat)file
5. SendingtheobjtffiletotheObjet3Dprinterforproduction
UsingObjetStudiotoperformthesetasksisdescribedindetailinchapter 5,
“UsingObjetStudio.”
Job Manager
TheJobManagerscreenisdifferentforclientworkstationsandforthe
computerconnecteddirectlytotheObjet3Dprinter.
• InObjetStudioinstalledonthedirectly‐connectedcomputer(server),
theJobManagerscreendisplaysthequeueandstatusforalljobssentto
the3Dprinterbytheserveritselfandbyallclientcomputersonthe
network.Alljobsdisplayedcanbe editedandmanipulated.
• InObjetStudioinstalledonclientcomputers,theJobManagerscreen
displaysthequeueandstatusonlyforjobssenttoa3Dprinterserver
fromthatcomputer.Onlythesejobscanbeeditedandmanipulated
fromtheclientcomputer.
Client computers can be connected, via the local network, to different Objet
3D printers, but only to one at a time. The Job Manager screen displays the
status of the 3D printer to which the client is currently connected.
