5. DisconnecttheUV‐lamppowerconnectorandtheUVheatfuse
connector.
Figure 6-104: Disconnecting the UV lamp
Note: Do not disconnect the power connection to the cooling fans.
6. LoosenthescrewsecuringtheUVlampcover(A),andpullthecover
up
(B),thenout(C).
Figure 6-105: Removing the UV lamp cover
7. Pullthelampreflectoroutoftheprintblock.
Figure 6-106: Removing the UV lamp reflector
