OnAir 2000M2 Digital Mixing Console
Date printed: 12.11.03 SW V 4.0 Diagnostics 14-3
Diagnostics and Error Handling – System Configuration Detection
Error ID Type Indication Diag. Box Error Text (Conflict)
000 Information no no Module for Channels [n] - [m] installed!
001 Information yes no Module for Channels [n] - [m] added!
002 Warning yes no Module for Channels [n] - [m] removed!
003 Information no no Central Module installed!
004 Information no no Central Module added!
005 Error yes yes No communication to Central Module!
006 Information no no Input Module for Channel [n] installed!
007 Information yes no Input Module for Channel [n] added!
008 Warning yes no Input Module for Channel [n] removed!
009 Information yes no Channel [n] Input Type changed to Mic Input!
010 Information yes no Channel [n] Input Type changed to Analog Line Input!
011 Information yes no Channel [n] Input Type changed to Digital Line Input!
012 Information yes no Channel [n] Input Selector changed to A/B!
013 Information yes no Channel [n] Input Selector changed to 1/2/3/4/5/6!
014 Information no no Digital Output Module for [output] installed!
015 Information yes no Digital Output Module for [output] added!
016 Warning yes no Digital Output Module for [output] removed!
017 Information yes no Insert [n/m] Input Type changed to Analog Line Input!
018 Information yes no Insert [n/m] Input Type changed to Digital Line Input!
019 Information no no Monitoring Module installed!
020 Information yes no Monitoring Module added!
021 Error yes yes No communication to Monitoring Module!
022 Information no no Time Sync Module installed!
023 Information yes no Time Sync Module added!
024 Warning yes no Time Sync Module removed!
025 Information no no Insert [n/m] Module installed!
026 Information yes no Insert [n/m] Module added!
027 Warning yes no Insert [n/m] Module removed!
028 Information no no Sync Module installed!
029 Information yes no Sync Module added!
030 Warning yes no Sync Module removed - Now Running on 48 kHz internal
Clock Reference!
031 Information no no Telephone Hybrid Control Module installed!
032 Information yes no Telephone Hybrid Control Module added!
033 Warning yes no Telephone Hybrid Control Module removed!
034 Information no no Channel DSP for Channel [m/n] installed!
035 Information yes no Channel DSP for Channel [m/n] added!
036 Warning yes yes No communication to Channel DSP for Channel [m/n]!
038 Information yes no Number of Channels increased to [n]!
039 Warning yes no Number of Channels decreased to [n]!
043 Information no no Sum DSP installed!
044 Warning yes yes No communication to Sum DSP!
045 Information no no Insert DSP installed!
046 Warning yes yes No communication to Insert DSP!
047 Information no no Aux DSP installed!
048 Warning yes yes No communication to Aux DSP!
049 Information yes no Channel Front Board type is OnAir 2000!
050 Information yes no Channel Front Board type is OnAir 1000!
156 Information yes no
Number of Faders increased to [n]! (n in hexadecimal)
157 Information yes no
Number of Faders decreased to [n]! (n in hexadecimal)
158 Information yes no Channel Routing reset to 1:1 mapping, since the number of
Channels has been changed!
159 Information yes no Channel Routing reset to 1:1 mapping, since the number of
Faders has been changed!
Diagnostics and Error Handling – Hardware Performance
Error ID Type Indication Diag. Box Error Text (Conflict)
051 Warning yes yes Watch RTC Failure!
- RTC Device Missing
- Device Faulty
- Battery Low
052 Warning yes no Missing External Clock - Now Running on 48 kHz internal
Clock Reference!
053 Warning yes no Missing External Video Clock
