Taski AERO 3500 micro - Page 115

GTS Technical Manual
9. April 2021 Edition: V1.00/2021 6-19
Copyright © 2020, Diversey
06.18.30 electronics - connections - 2100µicro_4000_5000_3500µicro_V2.00.fm
29 X61 Chem. (IntelliDose) 3 Pulse (Signal)
29 X61 Chem. (IntelliDose) 4 GND
30 X45 Waste water (Sensor) 1 Plus (+) 24VDC, (TASKI swingo 4000/5000)
30 X45 Waste water (Sensor) 2 Not connected, (TASKI swingo 4000/5000)
30 X45 Waste water (Sensor) 3 GND, (TASKI swingo 4000/5000)
30 X45 Waste water (Sensor) 4 SWS_IN (Signal), (TASKI swingo 4000/5000)
31 X44 Fresh water (Sensor) 1 Plus (+) 24VDC, (TASKI swingo 4000/5000)
31 X44 Fresh water (Sensor) 2 Not connected, (TASKI swingo 4000/5000)
31 X44 Fresh water (Sensor) 3 GND, (TASKI swingo 4000/5000)
31 X44 Fresh water (Sensor) 4 SWS_IN (Signal), (TASKI swingo 4000/5000)
32 X46 Encoder 1 Plus (+) 12VDC
32 X46 Encoder 2 GND
32 X46 Encoder 3 CHA
32 X46 Encoder 4 CHB
32 X46 Encoder 5 Shield
33 X50 TASKI Bus 1 CAN_H
33 X50 TASKI Bus 2 CAN_L
33 X50 TASKI Bus 3 Plus (+) 24VDC
33 X50 TASKI Bus 4 GND
Pos. Plug Description [plug] Pin Description [pin]
Table 2: Electronics connections
